MikroTik RB260GSP Switch

MikroTik CSS106-1G-4P-1S PoE switch. 4x PoE-out ports, 1x Gigabit, 1x SFP. Perfect for small devices and fiber-based networks.

SKU: CSS106-1G-4P-1S Category: Brand:
Guaranteed Safe Checkout

The MikroTik RB260GSP is a versatile SOHO smart switch. It is perfectly designed for small office or home network setups. This compact device features five Gigabit Ethernet ports. Crucially, ports 2-5 offer passive PoE-out capabilities. These can power other compatible PoE devices. It also includes one Gigabit SFP cage. This allows for flexible fiber optic uplink connections. The switch delivers reliable non-blocking performance.

MikroTik RB260GSP runs MikroTik’s specialized SwOS operating system. This system is optimized for switch-specific functions. SwOS is easily configurable through a simple web browser interface. This provides intuitive control over network settings. You can manage port-to-port forwarding. It allows for MAC filtering and VLAN configuration. Bandwidth limitation features are also available. The switch supports traffic mirroring.

This MikroTik switch excels in diverse applications. It is perfect for powering IP cameras or wireless access points directly. It efficiently manages data flow for improved performance. Its compact size allows flexible placement anywhere. This ensures seamless communication and data flow. The RB260GSP integrates easily into existing infrastructures. It also serves as a strong foundation for growing home or small business networks.

Specifications

{
“Specifications – Product code”: “CSS106-1G-4P-1S”,
“Specifications – Switch chip model”: “QCA8337”,
“Specifications – Dimensions”: “113x139x28mm”,
“Specifications – Operating System”: “MikroTik SwOS”,
“Specifications – Storage size”: “128 KB”,
“Specifications – Storage type”: “FLASH”,
“Specifications – MTBF”: “Approximately 100’000 hours at 25C”,
“Specifications – Tested ambient temperature”: “-20°C to 70°C”,
“Specifications – Suggested price”: “$55.95”,
“Powering – Number of DC inputs”: “2 (PoE-IN, DC jack)”,
“Powering – DC jack input Voltage”: “11-30 V”,
“Powering – Max power consumption”: “53 W”,
“Powering – Max power consumption without attachments”: “5 W”,
“Powering – Cooling type”: “Passive”,
“Powering – PoE in”: “Passive PoE”,
“Powering – PoE in input Voltage”: “11-30 V”,
“PoE-out – PoE-out ports”: “Ether2-Ether5”,
“PoE-out – PoE out”: “Passive PoE”,
“PoE-out – Max out per port output (input 18-30 V)”: “1 A”,
“PoE-out – Max total out (A)”: “2 A”,
“Ethernet – 10/100/1000 Ethernet ports”: “5”,
“Fiber – SFP DDMI”: “Yes”,
“Fiber – SFP ports”: “1”,
“Other – PCB temperature monitor”: “Yes”,
“Other – Voltage Monitor”: “Yes”,
“Certification & Approvals – Certification”: “CE, EAC, ROHS”,
“Certification & Approvals – IP”: “IP20”
}

DataSheet

Click Here for the DataSheet
