High-sensitivity PIR detector to realize accurate detection of wild animals and high-definition image acquisition with the detection range covering horizontal 90° ± 5°; Ultra-low power consumption: support sleep mode and performance mode. In sleep mode, the standby time can be up to 125 days; Support short-range WLAN AP function to conveniently debug, record, and preview the video; Clear imaging against strong back light due to 120 dB true WDR technology; Advanced infrared technology with IR distance up to 15 m; Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB; Supports LTE-TDD/LTE-FDD/WCDMA/GSM to realize wireless connection; Supports GPS positioning; Built-in microphone for real-time audio security
Available Models
DS-2XS6F45G1-IC2/4G(2.8mm); DS-2XS6F45G1-IC2/4G(6mm)
Specifications
Image Sensor: 1/3″ Progressive Scan CMOS; Max. Resolution: 2688 × 1520; Min. Illumination: Color: 0.005 Lux @ (F1.2, AGC ON),B/W: 0.001 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR; Shutter Time: 1 s to 1/100,000 s; Day & Night: IR cut filter; Focal Length & FOV: 2.8 mm, horizontal FOV 103.6°, vertical FOV 57.2°, diagonal FOV 121.6°
4 mm, horizontal FOV 81.1°, vertical FOV 48.6°, diagonal FOV 90.6°; Aperture: F1.6; Lens Mount: M12; DORI: 2.8 mm: D: 63.6 m, O: 25.2 m, R: 12.7 m, I: 6.4 m
4 mm: D: 66.0 m, O: 26.2 m, R: 13.2 m, I: 6.6 m; Supplement Light Type: IR; IR Wavelength: 850 nm; Supplement Light Range: Up to 15 m; Smart Supplement Light: Yes; Main Stream: 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720); Video Compression: Main stream: H.265; Video Bit Rate: 32 Kbps to 8 Mbps; H.265 Type: Baseline Profile,Main Profile,High Profile; Bit Rate Control: CBR,VBR; Scalable Video Coding (SVC): H.265; Environment Noise Filtering: Yes; Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/48 kHz; Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC; Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC); Audio Type: Mono sound; Simultaneous Live View: Up to 6 channels; API: ISAPI,SDK,ISUP; Protocols: TCP/IP, IPv6, DDNS, RTSP, HTTPS, HTTP, FTP, QoS, Bonjour, SNMP, WebSocket, WebSockets; User/Host: Up to 32 users
3 user levels: administrator, operator, and user; Network Storage: Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.; Client: iVMS-4200,Hik-Connect; Web Browser: Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,
Local service: Chrome 57.0+, Firefox 52.0+, Safari 13+, Edge 89+; Frequency: 4G model:
LTE-TDD Band 38/40/41
LTE-FDD Band 1/3/5/7/8/20/28
WCDMA Band 1/5/8
GSM 850/900/1800MHz
4G LA model：
LTE-TDD Band 38/40
LTE-FDD Band 1/2/3/4/5/7/8/28/66
WCDMA Band 1/2/3/4/5/8
GSM 850/900/1800/1900MHz; Standard: LTE-TDD/LTE-FDD/WCDMA/GSM; Day/Night Switch: Day,Night,Auto,Schedule; Wide Dynamic Range (WDR): 120 dB; Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.; Image Enhancement: BLC,HLC,Defog,3D DNR; Image Parameters Switch: Yes; Image Settings: Saturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser; SNR: ≥ 52 dB; Transducer Type: PIR; Detection Range: Up to 15 m; Detection Angle: 2.8 mm: Horizontal: 90° ± 5°, vertical: 25° ± 5°; 4 mm: Horizontal: 50° ± 5°, vertical: 20° ± 5°; Satellite Positioning Detection: Support GPS and searching longitude and latitude of the device; Built-in Microphone: 1 built-in microphone; On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB; Ethernet Interface: 1 six-core 1.25 mm interface (it can be transferred as 1 12 VDC coaxial interface and 1 RJ 45 10 m/100 m self-adaptive Ethernet port); Reset Key: Yes,
Press to switch between performance mode and proactive mode. Hold the button for 10 sec to restore to defaults.; Basic Event: Exception,PIR Alarm; Linkage: Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording; Power: 6 to 15 VDC, 1.03 to 0.73 A, max. 6.2 W; General Function: Heartbeat,one-key reset,anti-banding,password protection,watermark, IP address filter; Material: Plastic; Dimension: With antennas folded: 172.8 mm × 139.7 mm × 86.7 mm (6.8″ × 5.5″ × 3.4″), with antennas extending: 283.3 mm × 139.7 mm × 86.7 mm (11.2″ × 5.5″ × 3.4″); Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian; Package Dimension: 260 mm × 217 mm × 241 mm (10.2″ × 8.5″ × 9.5″); : Approx. 0.63 kg (1.39 lb.); With Package Weight: C1: approx. 1.588 kg (3.5 lb.), C2: approx. 1.848 kg (4.07 lb.); Storage Conditions: -20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing); Startup and Operating Conditions: -20 °C to 60 °C (-4 °F to 140 °F). Humidity 95% or less (non-condensing); Battery Type: Chargeable lithium battery or 5AA dry cell; Battery Voltage: Rated voltage: 7.2 VDC
Charging voltage: 8.4 VDC
Discharging cut-off voltage: 5.6 VDC; Capacity: 9.4 Ah; Operating Temperature: -20 °C to 60°C (-4 °F to 140 °F); Cycle Lifetime: Cycle lifetime is calculated under the condition that the camera captures pictures 10 times per day (9 times during the day and 1 time at night), uploads once per day, and keeps alive for 3 hours per day with the ambient temperature at 25 °C (77 °F).
Cycle lifetime: 125 days
Make sure the battery is fully charged before using the device.; RF: CE-RED: EN 301489-1 V2.2.3, EN 301489-17 V3.2.4, EN 301489-52 V1.2.1, EN 300 328 V2.2.2, EN IEC 62311:2020; EMC: CE-EMC: EN 55032:2015+A11:2020+A1:2020,EN 50130-4:2011+A1:2014,
RCM: AS/NZS CISPR 32: 2015; Safety: CB: IEC 62368-1: 2014+A11; Environment: CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006; Protection: IP67: IEC 60529-2013
