Hikvision 79GHz Entrance & Exit Radar DS-TMG035

Specifications

Transmitting Frequency: 79 GHz; Beamwidth: Vertical 10°, Horizontal 38°; Response Time (ms): 50ms; Trigger Distance (m): 0.1 to 6 m (adjustable); Detection Area (m): Horizontal width: 0 to 2 m (adjustable); Detection Target: Trigger Mode ：Vehicle
Anti-fall Mode ：Vehicle/Person; Online Debug: Serial port/Wi-Fi; Online Upgrade: Serial port/Wi-Fi upgrade; Transmitting Power: ≤ 10mW; Area Vehicle Following: Distinguish following distance of vehicle: 0.5 to 2 m (adjustable); Working Temperature and Humidity: -40℃~+85℃;; Working Current: ＜ 0.25A; Working Voltage: 9 to 12 VDC（With power adapter）; Power Consumption: ＜ 3W; Package Dimensions: Trigger Radar: 160 × 160 × 850 mm (6.3 × 6.3 × 33.5 inch)(L × W × H)
Anti-fall Radar: 148 × 115 × 65 mm (5.83 × 4.53 × 2.56 inch) (L × W × H); Dimensions: 96 × 60 × 29 mm (3.78 × 2.36 × 1.14 inch); Protection: IP67; : 0.35 kg (0.8 lb.); Weight (with Package): 1.1 kg (2.43 lb.)
