Hikvision All-in-one E&E machine with capture unit and LCD DS-TMC407-E

Specifications

Screen Dimensions: 21.5 inch; Resolution: 1080p; Panel Brightness: 1500 cd/m²（MAX）; Lens Type: 3.1 to 6 mm varifocal lens, motor-driven lens; Supplement Light Type: IR Light, Warm White Light; LED Light Bead: 9; Color Temperature: Warm White Light 3000 K; Image Format: JPEG with configurable quality; Capture Resolution: 2688 × 1520; Smart Recognition: ANPR, vehicle type recognition, vehicle logo recognition, sub-brand recognition; Image Settings: Saturation, brightness, contrast, white balance, AGC, and 3D noise reduction can be adjusted via the web browser.; Frame Rate: 25 fps @ (2688 × 1520); Video Compression: H.264/H.265/MJPEG; Video Bit Rate: 32 Kbps to 16 Mbps; Protocol: TCP/IP, HTTP, DHCP, DNS, RTP, RTSP, NTP, FTP picture upload; Security: Heartbeat, password protection, NTP; Alarm Input: 3-ch triggered/alarm inputs; Alarm Output: 2-ch relay outputs, supporting rising of barrier gate boom pole; Network Interface: 1 RJ45 10M/100M self-adaptive Ethernet interface; Serial Port: 1 built-in RS-485 serial port, 1 built-in RS-232 serial port; Max. Resolution: 2688 × 1520; Sensor Type: 1/3″ Progressive Scan CMOS; Min. Illumination: Color: 0.022 Lux @ (F2.0, AGC ON)
B/W: 0.011 Lux @ (F2.0, AGC ON); Shutter: 1/30 s to 1/100,000 s; Day/Night Switch: Supported; IR Cut Filter: Supported; Supplement Light Control: Control according to brightness or time; Lightning Protection: Supported; Working Temperature and Humidity: -20 °C to 70 °C (-4 °F to 158 °F); 90% or less (non-condensing); Power Supply: 220 VAC; Power Consumption: 85 W (with LCD); Dimensions: 1500 × 380 × 270 mm (59.1 × 15.0 × 10.6 inch); : 37 kg (81.6 lb.); Weight (with Package): 43.7 kg (96.3 lb.); Dimensions (with Package): 1650 x 402 x 508 mm (65.0 x 15.8 x 20.0 inch)
