Hikvision DS-UPS02K48-R/TJS (DS-UPS02K48-R/TJS)

Specifications

UPS Capacity: 2000 VA / 1800 W; Input Voltage Range: 110~300Vac (176~264Vac @ 100% load); Input Frequency: 40~70Hz (50/60Hz Auto-Sensing); Nominal Voltage: 208/220/230/240Vac; Phase: Single Phase; Power factor: ≥0.99; Output Frequency: Online mode: 46~54Hz or 56~64Hz
Bat. Mode: (50/60±0.1%)Hz; Transfer Time: AC mode to Bat.mode: 0ms
Inverter to Bypass: 4ms (Typical); Output Voltage: 208/220/230/240Vac; Power factor: 0.9; Output Sockets: IEC panel/EU panel/UK panel/US panel Optional; Crest factor: 3:1; Harmonic distortion (THDv): ≤3% Linear load
≤5% Non linear load; Output Waveform: Pure Sinewave; Battery Type: Valve Regulated Lead Acid (VRLA); Typical Recharging Time: 4 hours (To 90% of full capacity); Capacity (Standard Unit): 12V/9Ah; Battery Number: 4; DC System Voltage (VDC): 48V; Charging Current (Max.): 1A; Expandable Runtime: Yes, External battery pack: DS-UPSB0948B-R/TJC; Alarm: Battery mode/Battery low voltage /Overload/Fault; LCD display: Input voltage, Input frequency, Output voltage, Output frequency, Load percentage, Battery voltage, Inner temperature & Remaining battery backup time; AC Mode: 91%; Battery Mode: 87%; Operating Temperature: 0°C~40°C; Storage Temperature: -25°C~55°C; Humidity Range: 20~95%RH @ 0~40°C (Non condensing); Altitude: <1500m, derating required when>1500m; Noise Level: <50dB at 1 Meter; Dimension W x D x H (mm): 440 x 460 x 86.5; Net weight (kg): 19.5; Safety: CE-LVD, IEC/EN 62040-1, IEC/EN 62477-1; EMC: CE-EMC, IEC/EN 62040-2, IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-8
