Hikvision Gooseneck Paging Microphone DS-QAE0MG0G1
Hikvision Gooseneck Paging Microphone (DS-QAE0MG0G1) - Image 2

Hikvision Gooseneck Paging Microphone (DS-QAE0MG0G1)

Hikvision DS-QAE0MG0G1 audio matrix. Routes multiple audio sources to different zones for complex public address systems.

SKU: DS-QAE0MG0G1 Category: Brand:
Guaranteed Safe Checkout

The Hikvision DS-QAE0MG0G1 is a professional audio matrix designed for complex public address (PA) systems. It allows for the routing of multiple audio sources to different zones, providing precise control and flexible configuration. This device is ideal for large-scale installations like airports, stadiums, and shopping malls, ensuring seamless and targeted audio broadcasting.

Specifications

Type: electret; Pickup Range: 0.5 m; Frequency Response: 20 Hz to 20 kHz; Sensitivity: -30 dB (0 dB=1 V/Pa@1 kHz); SNR: 70 dB; Dynamic Range: 80 dB; Acoustic Overload Point (AOP): Overload sound 104 dB; Dimension of Sound Inlet Basket: Ø9.7 mm; LEQ: ≤24 dB; Adjustment Angel of Gooseneck: 360°; Input Current: ≤10 mA; Impedance: 120 Ω; Directivity: Cardioid; LED Indicator: Key indicator
Sound inlet basket indicator; Power: 48 V Phantom power,12VDC; Dimension: Base: 35 × 98 × 119 mm (1.38″ × 3.86″ × 4.69″)
Gooseneck: 409 mm (16.1″); : Approx. 0.59 kg (1.3 lb.); Package Dimension: 485 × 156 × 140 mm (19.1″ × 6.14″ × 5.51″); Packing List: microphone: x1
Power Supply: x1（12V D）
Regulatory Compliance and Safety Information × 1
XLR cable: x1; Operating Temperature: MAX.35 ℃ (95 °F)

DataSheet

Click Here for the DataSheet
