Hikvision IP Video Intercom Kit DS-KIS607-S

Specifications

Operation system: Embedded Linux operation system; Flash: 32 MB; RAM: 256MB; Supplement light: IR light, up to 3 m; Resolution: Main stream: 1920 × 1080p, 720p
Sub stream: 640 × 480p; Lens: 2MP HD camera; Wide dynamic range (WDR): Support 120 dB; FOV: Horizontal: 131° Vertical: 78°; Video Compression Standard: H.264; Motion detection: Support; Audio input: 1 built-in omnidirectional microphone; Audio output: 1 Built-in loudspeaker; Audio quality: Noise suppression and echo cancellation; Volume adjustment: Adjustable; Audio compression standard: G.711 U; Audio compression Rate: 64 Kbps; Network protocol: TCP/IP, RSTP; Network interface: 1 RJ-45, 10/100 Mbps self-adaptive; RS-485: 1; Alarm input: 4; Lock control: 1 relay, Max. 30 VDC 2 A; Exit button: 1; TAMPER switch: 1; Door contact input: 1; Button: 1 physical button(s); Power consumption: ＜ 10 W; Working temperature: -40 °C to 55 °C(-40 °F to 131 °F); Working humidity: 10% to 95% (no-condensing); Dimension: 138 mm × 65 mm × 27 mm (5.4″ × 2.6″ × 1.1″); Installation: Surface mounting; Protection level: IP65; Indicator: 2; Application environment: Outdoor; Power supply: IEEE802.3af, standard PoE
12 VDC; : Net weight: 0.190 kg Gross weight: 0.414 kg; Operation system: Embedded Linux operation system; Memory: 128 MB; Flash: 32 MB; Display screen: 7-inch colorful TFT screen; Display resolution: 1024 × 600; Operation method: Capacitive touch screen; Audio input: 1 built-in omnidirectional microphone; Audio output: 1 built-in loudspeaker; Audio quality: Noise suppression and echo cancellation; Audio compression standard: G.711 U, G.711 A; Audio compression Rate: 64 Kbps; Volume adjustment: Adjustable; Notice capacity: 200; Linked indoor extensions capacity: 16; Protocol: TCP/IP, SIP, RTSP; Wi-Fi: 2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n; Network interface: 1 RJ-45 10/100 Mbps self-adaptive; RS-485: 1; Alarm input: 8-ch alarm inputs; Alarm output: 2; TF card: Max to 128 G; Power consumption: ≤ 5 W; Power supply: 12 VDC,IEEE802.3af, Standard PoE; Working temperature: -10 °C to 50 °C (14 °F to 122 °F); Working humidity: 10% to 90%; Dimension (L x W x H): 175 mm × 113.5 mm × 21 mm (6.9″ × 4.5″ × 0.83″); Installation: Wall mounting, table mounting; Application environment: Indoor; : Net weight: 355 g (0.8 lb) Gross weight: 683 g (1.5 lb)
