Expand your wireless coverage significantly with the MikroTik cAP XL ac, a powerful and discreet ceiling/wall mount access point designed for larger spaces, available at Bridge Technologies. This “XL” version of the popular cAP series boasts an improved high-gain antenna, higher sensitivity, and a built-in reflector, boosting its covered area by up to 100% compared to previous models.
The cAP XL ac provides simultaneous dual-band Wi-Fi, supporting 2.4 GHz (802.11b/g/n with 6 dBi antenna gain) and 5 GHz (802.11a/n/ac with 5.5 dBi antenna gain). It delivers combined speeds up to AC1200 (300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz), ensuring blazing-fast and reliable connections across a wide 360-degree area. Its design allows it to blend seamlessly into any environment, resembling a smoke detector for inconspicuous placement.
Powered by a 4-core 716 MHz IPQ-4018 CPU and 128 MB of RAM, this access point can handle demanding network loads and complex RouterOS features, including IPsec hardware acceleration. It features two Gigabit Ethernet ports, with the first supporting 802.3af/at PoE input and the second offering passive PoE output (up to 57V). This PoE passthrough functionality is invaluable for extending your network with additional devices like IP cameras or other access points.
Running MikroTik’s comprehensive RouterOS (License Level 4), the cAP XL ac offers extensive configuration options for advanced network management, including firewall, routing, and bandwidth control. It’s an ideal solution for environments where maximum wireless coverage and discreet aesthetics are paramount, such as large offices, hotels, or expansive residential properties.
Choose the MikroTik cAP XL ac for an enterprise-grade, high-performance wireless access point that delivers superior coverage and versatile connectivity, all while maintaining a sleek and unobtrusive profile.
Specifications
{
“Specifications – Product code”: “RBcAPGi-5acD2nD-XL”,
“Specifications – Architecture”: “ARM 32bit”,
“Specifications – CPU”: “IPQ-4018”,
“Specifications – CPU core count”: “4”,
“Specifications – CPU nominal frequency”: “488-896 (auto) MHz”,
“Specifications – Switch chip model”: “IPQ-4018”,
“Specifications – Dimensions”: “191 x 42 mm”,
“Specifications – RouterOS license”: “4”,
“Specifications – Operating System”: “RouterOS”,
“Specifications – Size of RAM”: “128 MB”,
“Specifications – Storage size”: “16 MB”,
“Specifications – Storage type”: “FLASH”,
“Specifications – MTBF”: “Approximately 100’000 hours at 25C”,
“Specifications – Tested ambient temperature”: “-40°C to 70°C”,
“Specifications – IPsec hardware acceleration”: “Yes”,
“Specifications – Suggested price”: “$99.00”,
“Wireless capabilities – Wireless 2.4 GHz Max data rate”: “300 Mbit/s”,
“Wireless capabilities – Wireless 2.4 GHz number of chains”: “2”,
“Wireless capabilities – Wireless 2.4 GHz standards”: “802.11b/g/n”,
“Wireless capabilities – Antenna gain dBi for 2.4 GHz”: “6”,
“Wireless capabilities – Wireless 2.4 GHz chip model”: “IPQ-4018”,
“Wireless capabilities – Wireless 2.4 GHz generation”: “Wi-Fi 4”,
“Wireless capabilities – Wireless 5 GHz Max data rate”: “867 Mbit/s”,
“Wireless capabilities – Wireless 5 GHz number of chains”: “2”,
“Wireless capabilities – Wireless 5 GHz standards”: “802.11a/n/ac”,
“Wireless capabilities – Antenna gain dBi for 5 GHz”: “5.5”,
“Wireless capabilities – Wireless 5 GHz chip model”: “IPQ-4018”,
“Wireless capabilities – Wireless 5 GHz generation”: “Wi-Fi 5”,
“Wireless capabilities – WiFi speed”: “AC1200”,
“Ethernet – 10/100/1000 Ethernet ports”: “2”,
“Ethernet – Number of 1G Ethernet ports with PoE-out”: “1”,
“Powering – Number of DC inputs”: “1 (PoE-IN)”,
“Powering – Max power consumption”: “24 W”,
“Powering – Max power consumption without attachments”: “11 W”,
“Powering – Cooling type”: “Passive”,
“Powering – PoE in”: “802.3af/at”,
“Powering – PoE in input Voltage”: “18-57 V”,
“PoE-out – PoE-out ports”: “Ether2”,
“PoE-out – PoE out”: “Passive PoE up to 57V”,
“PoE-out – Max out per port output (input 18-30 V)”: “500 mA”,
“PoE-out – Max out per port output (input 30-57 V)”: “330 mA”,
“PoE-out – Max total out (A)”: “500 mA”,
“Certification & Approvals – Certification”: “CE, FCC, IC, EAC, ROHS”,
“Other – Mode button”: “Yes”,
“Wireless specifications – 1MBit/s”: “26”,
“Wireless specifications – 11MBit/s”: “26”,
“Wireless specifications – 6MBit/s”: “26”,
“Wireless specifications – 54MBit/s”: “21”,
“Wireless specifications – MCS0”: “26”,
“Wireless specifications – MCS7”: “20”,
“Wireless specifications – MCS9”: “18”
}
